STABILA LA-5P, 5 Point Layout Laser 03160

STABILA LA-5P, 5 Point Layout Laser 03160

Compare
SKU: STA:03160 Categories: ,

Description

This pouch laser is strong yet light. The mechanical on/off switch plus pendulum lock add to this tools reliability. It has 5 easy to see bright and tight laser dots. Builders with interior wall applications will appreciate that they can work directly against wood plates and metal track.

Features
STABILA Type LA-5P, Self leveling 5 point/dot laser with pouch, framing base, target plate, metal wall mount plate and batteries.
Transfer plumb points from floor to ceiling and layout right angles/square.
5 Bright tight dots visible over 50ft.
Up dot accuracy tolerance: Will not exceed 3/32in @ 30ft.
Down dot accuracy tolerance: Will not exceed 1/8 @ 30ft.
Level dot accuracy tolerance: Will not exceed 3/32in @ 30ft
Square dot accuracy tolerance: Will not exceed 1/16in @ 30ft
Warranty: Up to 2 years from the date of purchase.
Mechanical off/on switch with automatic pendulum lock.
V Groove rare earth magnetic mount is built into the housing.
Self -leveling range: 4.5 degrees
Up to 20 hours of run time on 3-AA batteries.

Applications
For positioning interior and partition walls up to 50ft. For transferring layout points from floor to ceiling.

Specifiations:
Laser class: 2
Output< 1 mW
Laser wavelength: 635 nm
Self-levelling range +/-4.50°
Levelling accuracy +/-3/16 in @ 30 ft
Laser beam accuracy (up) +/-3/16 in @ 30 ft
Laser beam accuracy (down) +/-1/8 in @ 30 ft
Measuring range of visible point: 60 ft
Operating life: 20 h
Battery type: AA
Protection class: IP 54
Tripod connection: 1/4″-20

Additional information

Weight 3 lbs
